Description
Kansai Special DLR-1508-SPF Oblique Belt Chain Stitching MachineDLR series flat bed multi-needle machine has options from 1 needle to 6 needles. It is a double chain stitch machine series with horizontal looper movement. The looper movement from left to right provides excellent sewing quality on thick denim fabric. It is suitable for sewing medium and thick fabrics. The highest sewing quality is achieved when attaching the belt with the independent foot system and metal rear puller. Side seam, waist elastic insertion, inner elastic insertion and 3 It gives excellent results with the puller system in strip applications. Features of the SPF system: Adjustable rear puller system: Both the upper and lower pullers are adjusted and fixed independently according to the indicators on the belt, depending on the desired slope on the belt. Right and left double gear system: The height settings of the right and left gear are different from each other. It can be adjusted individually according to the thickness of the fabric and the slope of the desired belt. Needle type: TVx5 21 Number of needles: 4 Number of threads: 8 Needle pitch options: 1/4-1-1/4, 1/4-7/8-1/415 with 08P The difference between 1509P is that 5 different needle spacing settings can be made in the 1509P model without the need to change parts. Number of sewing steps: 7-16 Foot lift height: 10 mm Needle bar movement: 34 mm Maximum speed: 4500 rpm Wheeled?Foot+Table+Motor is included. Disassembly is sent. Sub-Models and OptionsDLR: Model08: Number of needles02: 2 Needle03: 3 Needle04: 4 Needle08: 4 Needle09: 6 NeedleP: OptionsP: Rear pullerL: Piping apparatusPHD: Rear puller for thick materialsPMD: Rear puller and MD-1 measuring apparatusPR : Two-piece puller for sewing oblique beltsPTF: Rear puller and tractor footV: Without pullerSPF: Puller with angle adjustment for sewing oblique belts?
